RF and Wireless Techniques & Technologies
by
Prof. Eli Levin
CommTech Academy and Rohde & Schwarz Joint Venture
Up Coming Course
24/6/25
hybrid mode of distance/frontal learning
6 sessions of 4 hours each on Mondays 0900-1300 in the following dates:
24/6, 26/6, 1/7, 3/7, 8/7, 10/7 15/7.
and
17/7/25
The meeting will be held in Rohde & Schwarz Israel
The course price is 5900 NIS, Or
Only 5310 NIS Early bird discount until 27/5/25 for Online payment
additional discount for companies enrolling 3 participants or more
The course is delivered in Hebrew
hybrid mode of distance/frontal learning
Distance Learning at Virtual Classroom Using the Zoom Platform
Each session is a live online event, recording is made available on demand and online
In addition, there will a meeting that will be held in Rohde & Schwarz Israel
Course Overview
The course duration is 28 academic hours and will be delivered in hybrid mode of distance/frontal learning
6 distance learning meetings of 4 hours each and frontal 4 hours meeting at Rohde & Schwarz Israel
This is a comprehensive and intensive course. (see the course syllabus)
The course is presented by leading technical experts from industry and academia with many years of experience. (see Lecturers)
The course provides an introduction to fundamental as well as state of the art topics in modern RF, Microwave and Wireless Communications engineering.
The course first constitutes background of basic RF concepts, including Noise, Non-Linearity, Sensitivity, Dynamic Range, Transmission lines, S parameters, Impedance matching and more.
The course then reviews basic RF building blocks (Mixers, Oscillators, Filters etc.) describing how these are combined to form complete RF systems.
Advanced Digital Modulations is then presented.
The Course includes thorough description of Spectrum Analyzers, Signal Analyzers, Vector Network Analyzer, Electromagnetic Waves, Propagation of EM waves and Antennas.
The course concludes by defining important test and measurement terms and methods used to characterize RF components, RF modules up to full System performance.
This includes a series of practical demonstrations using modern RF test and measurement equipment.
SOK Rishon LeZion שדרות הראשונים 23, Rishon LeZion, 7519701
Our Certification confirms your enhanced technical skills.
The certificate is highly appreciated by the industry
Among Our Customers:
This course is now in its tenth year of offering.
Over the years, the course has established itself as the benchmark for training in the RF, Microwave, and Wireless industry.
Learning Management System (LMS)
Delivery of e-Learning content (including mobile), Assignments, Quizzes and Grades.
Administration, Documentation, Progress and Performance tracking, Assessment and extensive Reporting
Explore CommTech’s LMS wide range of features and available resources
Desktop, mobile, and tablet access
Microwave and RF design using Simulation software. Session conducted in a fully equipped computer class and includes practical hands on practicing
Computers Class
A series of thorough and broad hands-on tests accomplished with advanced state-of-the-art laboratory equipment
Lab Class
Spacious classroom, Well equipped, Pleasant atmosphere. Coffee and refreshments , Easy access location, Free parking
Frontal Class
Demos and hands on experience with:
The world’s most advanced
RF and Microwave
Test and Measurement equipment
Lab tests:
- Power measurements by several detectors (incl. peak, ave. and RMS)
- Sensitivity measurements (for QAM and Pulse signals) with averaging (using varying BV and screens averaging)
- Phase noise measurement of a frequency source
- Measurement of NF (of an amplifier and SSBNF of a mixer)
- Peak-to-Average measurement (PAPR)
- Measurement of third-order intercept point (IP3) and SFDR
Spectrum Analyzer
Lab tests:
- Basic calibration
- Improved calibration (suitable for reject band of filters)
- Measurement of BPF (S-parameters, Phase and delay response)
- Measurement of an Amplifier (AM/AM, AM/PM, 1dB comp., Harmonics)
- Measurement of load mismatch, and perform Single-Stub matching
- …
- …
Vector Network Analyzer-VNA
Lab tests:
- Perform a broadband calibration (de-embedding)
- EVM tests
- Measurement of I-Q imbalance and IR (image-rejection)
- BER measurement
- Measurement PAPR of a detailed-QAM-constellation
- Measurement of BW and ACPR
- Measurement of emission mask-compliance for a WCDMA signal without and with an amplifier
Vector Signal Analyzer-VSA
RF and MW Self Assessment Quiz
Try This Quiz to assesse your RF and Wireless knowledge. The Quiz contains 26 multi choice questions. Two questions per each course chapter
